Gas Burners

Idea

[kW 65 ÷ 570]
NG280 NG350 NG400 NG550

With the new line IDEA Low NOx Class 2 (< 120 mg/kWh) with tangential ventilation, CIB Unigas presents to the market a new concept of modern and functional burners for small and medium appliances. These burners, which are the most powerful of the range IDEA, are particularly suitable to work on boilers with high back pressure.

Technical Data NG280

Additional charges for LPG, Biogas and other types of gas: quote on request

Type Model Power min. Power max. Power supply Motor Fan
NG280 M-.AB.S.99.A.0.25 42 kW 300 kW 230 V 1N ac 0.25 kW
NG280 M-.AB.S.99.A.0.32 42 kW 300 kW 230 V 1N ac 0.25 kW
NG280 M-.AB.S.99.A.0.40 42 kW 300 kW 230 V 1N ac 0.25 kW
NG280 M-.PR.S.99.A.0.25 42 kW 300 kW 230 V 1N ac 0.25 kW
NG280 M-.PR.S.99.A.0.32 42 kW 300 kW 230 V 1N ac 0.25 kW
NG280 M-.PR.S.99.A.0.40 42 kW 300 kW 230 V 1N ac 0.25 kW
NG280 M-.PR.S.99.A.1.25.EA 42 kW 300 kW 230 V 1N ac 0.25 kW
NG280 M-.PR.S.99.A.1.32.EA 42 kW 300 kW 230 V 1N ac 0.25 kW
NG280 M-.PR.S.99.A.1.40.EA 42 kW 300 kW 230 V 1N ac 0.25 kW
NG280 M-.TN.S.99.A.0.25 42 kW 300 kW 230 V 1N ac 0.25 kW
NG280 M-.TN.S.99.A.0.32 42 kW 300 kW 230 V 1N ac 0.25 kW
NG280 M-.TN.S.99.A.0.40 42 kW 300 kW 230 V 1N ac 0.25 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.

Technical Data NG350

Additional charges for LPG, Biogas and other types of gas: quote on request

Type Model Power min. Power max. Power supply Motor Fan
NG350 M-.TN.S.99.A.0.15 80 kW 330 kW 230 V 1N ac 0.37 kW
NG350 M-.PR.M.99.A.0.25 80 kW 330 kW 230 V 1N ac 0.37 kW
NG350 M-.PR.M.99.A.0.32 80 kW 330 kW 230 V 1N ac 0.37 kW
NG350 M-.PR.M.99.A.0.40 80 kW 330 kW 230 V 1N ac 0.37 kW
NG350 M-.PR.M.99.A.1.25.EA 80 kW 330 kW 230 V 1N ac 0.37 kW
NG350 M-.PR.M.99.A.1.32.EA 80 kW 330 kW 230 V 1N ac 0.37 kW
NG350 M-.PR.M.99.A.1.40.EA 80 kW 330 kW 230 V 1N ac 0.37 kW
NG350 M-.TN.M.99.A.0.25 80 kW 330 kW 230 V 1N ac 0.37 kW
NG350 M-.TN.M.99.A.0.32 80 kW 330 kW 230 V 1N ac 0.37 kW
NG350 M-.TN.M.99.A.0.40 80 kW 330 kW 230 V 1N ac 0.37 kW

Technical Data NG400

Additional charges for LPG, Biogas and other types of gas: quote on request

Type Model Power min. Power max. Power supply Motor Fan
NG400 M-.PR.M.99.A.0.25 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.0.32 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.0.40 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.0.50 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.1.25.EA 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.1.32.EA 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.1.40.EA 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.1.50.EA 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.TN.M.99.A.0.25 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.TN.M.99.A.0.32 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.TN.M.99.A.0.40 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.TN.M.99.A.0.50 115 kW 420 kW 230 V 1N ac 0.37 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.

Technical Data NG550

Additional charges for LPG, Biogas and other types of gas: quote on request

Type Model Power min. Power max. Power supply Motor Fan
NG400 M-.PR.M.99.A.0.25 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.0.32 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.0.40 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.0.50 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.1.25.EA 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.1.32.EA 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.1.40.EA 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.PR.M.99.A.1.50.EA 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.TN.M.99.A.0.25 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.TN.M.99.A.0.32 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.TN.M.99.A.0.40 115 kW 420 kW 230 V 1N ac 0.37 kW
NG400 M-.TN.M.99.A.0.50 115 kW 420 kW 230 V 1N ac 0.37 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
