[kW 35 ÷ 200]
Tecnopan S5 Tecnopan S10, Tecnopan S18 Chef S5
[kW 35 ÷ 200]
Tecnopan S5 Tecnopan S10, Tecnopan S18 Chef S5
This burners series has been produced to work on bakery and rotary ovens. These burners are used, especially, in commercial kitchens, big hotels and restaurants. They feature the same main characteristics of the standard burners plus the possibility to manually decrease the output up to 40% on light oil burners, and up to 50% on gas burners. On the burner case we have installed an ON-OFF switch and a switch to regulate the output. These burners are equipped with a double protection shield and a blast tube in thermalsteel for high temperature operation.
Additional charges for LPG, Biogas and other types of gas: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| S5 | M-.TN.S.99.B.0.15 | 35 kW | 70 kW | 230 V 1N ac | 0.1 kW |
| S5 | M-.TN.S.99.D.0.15 | 35 kW | 70 kW | 230 V 1N ac | 0.1 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
Additional charges for LPG, Biogas and other types of gas: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| S10 | M-.TN.S.99.B.0.20 | 65 kW | 120 kW | 230 V 1N ac | 0.15 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
Additional charges for LPG, Biogas and other types of gas: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| S18 | M-.TN.S.99.B.0.25 | 80 kW | 200 kW | 230 V 1N ac | 0.15 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
