MINIFLAME

This burner, in the standard version, is suitable to burn oil with a max viscosity of 50 cSt at 50 °C (7° E at 50°). A version adaptable to burn oil with max viscosity of 110 cSt at 50 °C (15° E at 50°), is available upon request. The oil heater consists of a tank equipped with an electric element while a system of preset thermostats controls the regulation of the fuel temperature in order to ensure the optimum performance of the flue used. The burner is provided with a cover to protect the internal components which is easily removable in case of maintenance interventions. The links to the electrical supply line and to the temperature regulators are quite easy and safe thanks to the pre-wired connectors. Upon request we can supply the components necessary to ensure that the oil supply line complies with UNI 9248.
