Heavy Oil Burners

NOVANTA-CINQUECENTO

[kW 550 ÷ 8000]
PN91 PN92 PN93 RN510 RN515 RN520 RN525

These aluminium monoblock industrial burners with integral fan are available for oils with viscosity up to 110 cSt at 50°C (15°E at 50°C). Upon request we can also supply a model for heavy oils up to 400 cSt at 50° C (50°E at 50°C). Given the particular viscosity of the fuel and the necessity to keep the oil fluid, the burner uses a preheating system provided with a much lower thermal load electrical element in order to avoid carbon deposits. The maintenance is always easy given that the components – for example the solenoid valve group - are mounted on a specific bracket which can be easily removed.

Technical Data PN91

Additional charges for petroleum, waste oil and other types of oils: quote on request

Type Model Power min. Power max. Power supply Motor Fan
PN91 N-.AB.S.XX.A 698 kW 2093 kW 400 V / 3AC 50Hz 4 kW
PN91 N-.PR.S.XX.A 698 kW 2093 kW 400 V / 3AC 50Hz 4 kW
PN91 N-.MD.S.XX.A.ES 698 kW 2093 kW 400 V / 3AC 50Hz 4 kW
PN91 N-.MD.S.XX.A 698 kW 2093 kW 400 V / 3AC 50Hz 4 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.

Technical Data PN92

Additional charges for petroleum, waste oil and other types of oils: quote on request

Type Model Power min. Power max. Power supply Motor Fan
PN92 N-.PR.S.XX.A 849 kW 2558 kW 400 V / 3AC 50Hz 5,5 kW
PN92 N-.MD.S.XX.A 849 kW 2558 kW 400 V / 3AC 50Hz 5,5 kW
PN92 N-.MD.S.XX.A.ES 849 kW 2558 kW 400 V / 3AC 50Hz 5,5 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.

Technical Data PN93

Additional charges for petroleum, waste oil and other types of oils: quote on request

Type Model Power min. Power max. Power supply Motor Fan
PN93 N-.PR.S.XX.A 550 kW 4100 kW 400 V / 3AC 50Hz 7,5 kW
PN93 N-.MD.S.XX.A 550 kW 4100 kW 400 V / 3AC 50Hz 7,5 kW
PN93 N-.MD.S.XX.A.ES 550 kW 4100 kW 400 V / 3AC 50Hz 7,5 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.

Technical Data PN93

Additional charges for petroleum, waste oil and other types of oils: quote on request

Type Model Power min. Power max. Power supply Motor Fan
RN510 N-.PR.S.XX.A 1314 kW 3953 kW 400 V / 3 AC 50Hz 7,5 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.

Technical Data RN515

Additional charges for petroleum, waste oil and other types of oils: quote on request

Type Model Power min. Power max. Power supply Motor Fan
RN515 N-.PR.S.XX.A 1628 kW 4884 kW 400 V / 3 AC 50Hz 11 kW
RN515 N-.MD.S.XX.A 1628 kW 4884 kW 400 V / 3 AC 50Hz 11 kW
RN515 N-.MD.S.XX.A.ES 1628 kW 4884 kW 400 V / 3 AC 50Hz 11 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.

Technical Data RN520

Additional charges for petroleum, waste oil and other types of oils: quote on request

Type Model Power min. Power max. Power supply Motor Fan
RN520 N-.PR.S.XX.A 2326 kW 6977 kW 400 V / 3 AC 50Hz 15 kW
RN520 N-.MD.S.XX.A 2326 kW 6977 kW 400 V / 3 AC 50Hz 15 kW
RN520 N-.MD.S.XX.A.ES 2326 kW 6977 kW 400 V / 3 AC 50Hz 15 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.

Technical Data RN525

Additional charges for petroleum, waste oil and other types of oils: quote on request

Type Model Power min. Power max. Power supply Motor Fan
RN525 N-.PR.S.XX.A 2000 kW 8000 kW 400 V / 3 AC 50Hz 18,5 kW
RN525 N-.MD.S.XX.A 2000 kW 8000 kW 400 V / 3 AC 50Hz 18,5 kW
RN525 N-.MD.S.XX.A.ES 2000 kW 8000 kW 400 V / 3 AC 50Hz 18,5 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
