[kW 550 ÷ 8000]
RG91 RG92 RG93 RG510 RG515 RG520 RG525
[kW 550 ÷ 8000]
RG91 RG92 RG93 RG510 RG515 RG520 RG525
This series of monoblock burners made of a solid diecast aluminium housing, represents the outcome of our experience in the field of medium-large capacity burners. This version of burners owns a centrifugal air fan activated by a three phase motor, while the oil pump works through a dedicated motor. This range is divided into two groups: the series NOVANTA with a capacity up to 4100kW and the series CINQUECENTO that gains a maximum capacity of 8000kW. Both series are equipped with a by-passing nozzle that allows a modulating ratio of 1:3. The light oil output can be adjusted through a pressure regulator which effects on the return pipe line. All burners have a control panel which includes the control box and the regulators of temperature and pressure. Furthermore they own a mimic diagram with lamps showing the sequential stages of the burner operation.
Additional charges for Biodiesel, Kerosene and other types of oils: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| RG91 | G-.AB.S.XX.A | 1047 kW | 2093 kW | 400 V / 3N AC 50Hz | 4 kW |
| RG91 | G-.PR.S.XX.A | 698 kW | 2093 kW | 400 V / 3N AC 50Hz | 4 kW |
| RG91 | G-.PR.S.XX.A.EA | 698 kW | 2093 kW | 400 V / 3N AC 50Hz | 4 kW |
| RG91 | G-.MD.S.XX.A | 698 kW | 2093 kW | 400 V / 3N AC 50Hz | 4 kW |
| RG91 | G-.MD.S.XX.A.ES | 698 kW | 2093 kW | 400 V / 3N AC 50Hz | 4 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
Additional charges for Biodiesel, Kerosene and other types of oils: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| RG92 | G-.PR.S.XX.A | 849 kW | 2558 kW | 400 V / 3N AC 50Hz | 5,5 kW |
| RG92 | G-.PR.S.XX.A.EA | 849 kW | 2558 kW | 400 V / 3N AC 50Hz | 5,5 kW |
| RG92 | G-.MD.S.XX.A | 849 kW | 2558 kW | 400 V / 3N AC 50Hz | 5,5 kW |
| RG92 | G-.MD.S.XX.A.ES | 849 kW | 2558 kW | 400 V / 3N AC 50Hz | 5,5 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
Additional charges for Biodiesel, Kerosene and other types of oils: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| RG93 | G-.PR.S.XX.A | 550 kW | 4100 kW | 400 V / 3N AC 50Hz | 7,5 kW |
| RG93 | G-.PR.S.XX.A.EA | 550 kW | 4100 kW | 400 V / 3N AC 50Hz | 7,5 kW |
| RG93 | G-.MD.S.XX.A | 550 kW | 4100 kW | 400 V / 3N AC 50Hz | 7,5 kW |
| RG93 | G-.MD.S.XX.A.ES | 550 kW | 4100 kW | 400 V / 3N AC 50Hz | 7,5 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
Additional charges for Biodiesel, Kerosene and other types of oils: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| RG510 | G-.PR.S.XX.A | 1314 kW | 3939 kW | 400 V / 3N AC 50Hz | 7,5 kW |
| RG510 | G-.MD.S.XX.A | 1314 kW | 3939 kW | 400 V / 3N AC 50Hz | 7,5 kW |
| RG510 | G-.PR.S.XX.A.EA | 1314 kW | 3939 kW | 400 V / 3N AC 50Hz | 7,5 kW |
| RG510 | G-.MD.S.XX.A.ES | 1314 kW | 3939 kW | 400 V / 3N AC 50Hz | 7,5 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
Additional charges for Biodiesel, Kerosene and other types of oils: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| RG515 | G-.PR.S.XX.A | 1628 kW | 4884 kW | 400 V / 3N AC 50Hz | 11 kW |
| RG515 | G-.MD.S.XX.A | 1628 kW | 4884 kW | 400 V / 3N AC 50Hz | 11 kW |
| RG515 | G-.PR.S.XX.A.EA | 1628 kW | 4884 kW | 400 V / 3N AC 50Hz | 11 kW |
| RG515 | G-.MD.S.XX.A.ES | 1628 kW | 4884 kW | 400 V / 3N AC 50Hz | 11 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
Additional charges for Biodiesel, Kerosene and other types of oils: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| RG520 | G-.PR.S.XX.A | 2000 kW | 8000 kW | 400 V / 3N AC 50Hz | 18,5 kW |
| RG520 | G-.MD.S.XX.A.ES | 2326 kW | 6977 kW | 400 V / 3N AC 50Hz | 15 kW |
| RG520 | G-.PR.S.XX.A.EA | 2326 kW | 6977 kW | 400 V / 3N AC 50Hz | 15 kW |
| RG520 | G-.MD.S.XX.A | 2326 kW | 6977 kW | 400 V / 3N AC 50Hz | 15 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
Additional charges for Biodiesel, Kerosene and other types of oils: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| RG525 | G-.PR.S.XX.A | 2000 kW | 8000 kW | 400 V / 3N AC 50Hz | 18,5 kW |
| RG525 | G-.MD.S.XX.A | 2000 kW | 8000 kW | 400 V / 3N AC 50Hz | 18,5 kW |
| RG525 | G-.PR.S.XX.A.EA | 2000 kW | 8000 kW | 400 V / 3N AC 50Hz | 18,5 kW |
| RG525 | G-.MD.S.XX.A.ES | 2000 kW | 8000 kW | 400 V / 3N AC 50Hz | 18,5 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
