[kW 29 ÷ 209]
Tecnopan G6 Tecnopan G10, Tecnopan G18 Chef G5 Chef G6
[kW 29 ÷ 209]
Tecnopan G6 Tecnopan G10, Tecnopan G18 Chef G5 Chef G6
This series of burners is appropriate to work on bakery and rotary or fixed ovens. These burners are used especially by commercial kitchens, big hotels and restaurants. They features the same main characteristics of the standard burners plus the possibility to manually decrease the output up to 40% on light oil burners and up to 50% on gas burners. On the burner case we have installed an ON/OFF switch an another switch to regulate the output. These burners are equipped with a double protection shield and a blast tube in thermalsteel for high temperature operation.
Additional charges for Biodiesel, Kerosene and other types of oils: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| G5 | G-.TN.S.99.D | 29 kW | 35 kW | 230 V 1N ac | 0.1 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
Additional charges for Biodiesel, Kerosene and other types of oils: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| G6 | G-.TN.S.99.B | 30 kW | 70 kW | 230 V 1N ac (Disponibile anche in 24 Volt DC) | 0.1 kW |
| G6 | G-.TN.S.99.D | 30 kW | 70 kW | 230 V 1N ac (Disponibile anche in 24 Volt DC) | 0.1 kW |
| G6 | G-.TN.S.99.Y | 30 kW | 70 kW | 230 V 1N ac (Disponibile anche in 24 Volt DC) | 0.1 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
Additional charges for Biodiesel, Kerosene and other types of oils: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| G10 | G-.TN.S.99.B | 58 kW | 116 kW | 230 V 1N ac (Disponibile anche in 24 Volt DC) | 0.15 kW |
| G10 | G-.TN.S.99.Y | 58 kW | 116 kW | 230 V 1N ac (Disponibile anche in 24 Volt DC) | 0.15 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
Additional charges for Biodiesel, Kerosene and other types of oils: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| G18 | G-.TN.S.99.B | 105 kW | 209 kW | 230 V 1N ac (Disponibile anche in 24 Volt DC) | 0.18 kW |
| G18 | G-.TN.S.99.Y | 105 kW | 209 kW | 230 V 1N ac (Disponibile anche in 24 Volt DC) | 0.18 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
