[kW 40 ÷ 150]
NGX120 NGX200
[kW 40 ÷ 150]
NGX120 NGX200
These burners are suitable for all type of pressurized boilers up to 150 kW. Thanks to the arrangement of the electronic and mechanical components, these burners are easy to use and to maintain and they guarantee performance maximization and optimal air/fuel mixing. All these features are achieved thanks to the new combustion head that allows a staged air flow in order to let the flame burn progressively along the length of the combustion chamber.
Additional charges for LPG, Biogas and other types of gas: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| NGX120 | M-.AB.S.99.A.0.15 | 35 kW | 120 kW | 230 V 1N ac | 0.18 kW |
| NGX120 | M-.AB.S.99.A.0.20 | 35 kW | 120 kW | 230 V 1N ac | 0.18 kW |
| NGX120 | M-.AB.S.99.A.0.25 | 35 kW | 120 kW | 230 V 1N ac | 0.18 kW |
| NGX120 | M-.PR.S.99.A.0.15 | 35 kW | 120 kW | 230 V 1N ac | 0.18 kW |
| NGX120 | M-.PR.S.99.A.0.20 | 35 kW | 120 kW | 230 V 1N ac | 0.18 kW |
| NGX120 | M-.PR.S.99.A.0.25 | 35 kW | 120 kW | 230 V 1N ac | 0.18 kW |
| NGX120 | M-.TN.S.99.A.0.15 | 35 kW | 120 kW | 230 V 1N ac | 0.18 kW |
| NGX120 | M-.TN.S.99.A.0.20 | 35 kW | 120 kW | 230 V 1N ac | 0.18 kW |
| NGX120 | M-.TN.S.99.A.0.25 | 35 kW | 120 kW | 230 V 1N ac | 0.18 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
Additional charges for LPG, Biogas and other types of gas: quote on request
| Type | Model | Power min. | Power max. | Power supply | Motor Fan |
|---|---|---|---|---|---|
| NGX200 | M-.AB.S.99.A.0.20 | 40 kW | 150 kW | 230 V 1N ac | 0.18 kW |
| NGX200 | M-.AB.S.99.A.0.25 | 40 kW | 150 kW | 230 V 1N ac | 0.18 kW |
| NGX200 | M-.PR.S.99.A.0.20 | 40 kW | 150 kW | 230 V 1N ac | 0.18 kW |
| NGX200 | M-.PR.S.99.A.0.25 | 40 kW | 150 kW | 230 V 1N ac | 0.18 kW |
| NGX200 | M-.TN.S.99.A.0.20 | 40 kW | 150 kW | 230 V 1N ac | 0.18 kW |
| NGX200 | M-.TN.S.99.A.0.25 | 40 kW | 150 kW | 230 V 1N ac | 0.18 kW |
NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
