Gas Burners

IDEA LOW NOx

[kW 60 ÷ 490]
NGX280 NGX350 NGX400 NGX550

The burners of the series IDEA Low NOx Class 3 (<80 mg/KWh) covering this output range, have been provided with a very advanced and performing combustion head which ensure a stable combustion in all working conditions. The placement of the components inside the burner permits an easy and precise regulation and maintenance.

Technical Data NGX280

Additional charges for LPG, Biogas and other types of gas: quote on request

Type Model Power min. Power max. Power supply Motor Fan
NGX280 M-.AB.S.99.A.0.25 60 kW 190 kW 230 V 1N ac 0.18 kW
NGX280 M-.AB.S.99.A.0.32 60 kW 190 kW 230 V 1N ac 0.18 kW
NGX280 M-.AB.S.99.A.0.40 60 kW 190 kW 230 V 1N ac 0.18 kW
NGX280 M-.PR.S.99.A.0.25 60 kW 190 kW 230 V 1N ac 0.18 kW
NGX280 M-.PR.S.99.A.0.32 60 kW 190 kW 230 V 1N ac 0.18 kW
NGX280 M-.PR.S.99.A.0.40 60 kW 190 kW 230 V 1N ac 0.18 kW
NGX280 M-.PR.S.99.A.1.25.EA 60 kW 190 kW 230 V 1N ac 0.18 kW
NGX280 M-.PR.S.99.A.1.32.EA 60 kW 190 kW 230 V 1N ac 0.18 kW
NGX280 M-.PR.S.99.A.1.40.EA 60 kW 190 kW 230 V 1N ac 0.18 kW
NGX280 M-.TN.S.99.A.0.25 60 kW 190 kW 230 V 1N ac 0.18 kW
NGX280 M-.TN.S.99.A.0.32 60 kW 190 kW 230 V 1N ac 0.18 kW
NGX280 M-.TN.S.99.A.0.40 60 kW 190 kW 231 V 1N ac 0.25 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.

Technical Data NGX350

Additional charges for LPG, Biogas and other types of gas: quote on request

Type Model Power min. Power max. Power supply Motor Fan
NGX350 M-.TN.S.99.A.0.15 65 kW 260 kW 231 V 1N ac 0.37 kW
NGX350 M-.PR.M.99.A.0.25 65 kW 260 kW 231 V 1N ac 0.37 kW
NGX350 M-.PR.M.99.A.0.32 65 kW 260 kW 231 V 1N ac 0.37 kW
NGX350 M-.PR.M.99.A.0.40 65 kW 260 kW 231 V 1N ac 0.37 kW
NGX350 M-.PR.M.99.A.1.25.EA 65 kW 260 kW 231 V 1N ac 0.37 kW
NGX350 M-.PR.M.99.A.1.32.EA 65 kW 260 kW 231 V 1N ac 0.37 kW
NGX350 M-.PR.M.99.A.1.40.EA 65 kW 260 kW 231 V 1N ac 0.37 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.

Technical Data NGX400

Additional charges for LPG, Biogas and other types of gas: quote on request

Type Model Power min. Power max. Power supply Motor Fan
NGX400 M-.PR.M.99.A.0.25 90 kW 350 kW 231 V 1N ac 0.37 kW
NGX400 M-.PR.M.99.A.0.32 90 kW 350 kW 231 V 1N ac 0.37 kW
NGX400 M-.PR.M.99.A.0.40 90 kW 350 kW 231 V 1N ac 0.37 kW
NGX400 M-.PR.M.99.A.0.50 90 kW 350 kW 231 V 1N ac 0.37 kW
NGX400 M-.PR.M.99.A.1.25.EA 90 kW 350 kW 231 V 1N ac 0.37 kW
NGX400 M-.PR.M.99.A.1.32.EA 90 kW 350 kW 231 V 1N ac 0.37 kW
NGX400 M-.PR.M.99.A.1.40.EA 90 kW 350 kW 231 V 1N ac 0.37 kW
NGX400 M-.PR.M.99.A.1.50.EA 90 kW 350 kW 231 V 1N ac 0.37 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.

Technical Data NGX550

Additional charges for LPG, Biogas and other types of gas: quote on request

Type Model Power min. Power max. Power supply Motor Fan
NGX550 M-.PR.S.99.A.0.15 132 kW 490 kW 231 V 1N ac 0.62 kW
NGX550 M-.PR.S.99.A.0.20 132 kW 490 kW 231 V 1N ac 0.62 kW
NGX550 M-.PR.S.99.A.0.32 132 kW 490 kW 231 V 1N ac 0.62 kW
NGX550 M-.PR.S.99.A.0.40 132 kW 490 kW 231 V 1N ac 0.62 kW
NGX550 M-.PR.S.99.A.0.50 132 kW 490 kW 231 V 1N ac 0.62 kW
NGX550 M-.PR.S.99.A.1.32.EA 132 kW 490 kW 231 V 1N ac 0.62 kW
NGX550 M-.PR.S.99.A.1.40.EA 132 kW 490 kW 231 V 1N ac 0.62 kW
NGX550 M-.PR.S.99.A.1.50.EA 132 kW 490 kW 231 V 1N ac 0.62 kW

NOTE: The above models differ in the type of ramp connection, regulation and type of control (mechanical/electronic). If in doubt, contact our sales offices.
